Always a step ahead! The smart and innovative Zone 2/Cl I Div2-smartphone with the most advanced technology: First Bluetooth^® 5.0 industrial smartphone with multifunctional ISM interface, a huge internal memory 64 GB and the highest camera resolution of its class.

ADVANTAGES

• Android^TM 9.0
• 4G (LTE)
• Bluetooth® 5.0
• 4,5“ (11.43 cm) Gorilla Glass® 3. Generation
• Quick charge with magnetic charging port
• Universal, lateral ISM interface
• PTT ready (third party application provided)
• Usable with gloves

Información Técnica

Technical Data

Type	IS530.2
Operating System	AndroidTM 9.0
Size	155 x 80 x 25 mm
Weight	325 g
PTT ready	optional (third party application provided)
LWP ready	optional (third party application provided)
Bluetooth®	5.0
Frequencies	GSM 850/900/1800/1900 MHz WCDMA UMTS B1/B2/B4/B5/B8 LTE-TDD B38/B39/B40/B41 LTE-FDD B1/B2/B3/B4/B5/B7/B8/B12 mit MFBI B13/B14/B17/B20/B25/B26/B28A/B28B/B29/B30/B66 TD-SCDMA B34/B39
Wi-Fi®	2,4 GHz + 5 GHz IEEE 802.11 a/b/g/n/ac/e/k/r/h with max. 8 connections hotspot
NFC	Near Field Comunication
Display	4,5“ (11.43 cm) Gorilla Glass® 3. generation, usable with gloves
Processor	Qualcomm Snapdragon SDM660 Octa-Core
Memory	64 GB internal memory, 54 GB accessible
Micro-SD	up to 128 GB
Camera	2 cameras, 13 MP AF rear camera and 5 MP front camera
Battery	3600 mAh battery (replaceable)
Operation range from	-20 °C to 60 °C
Security updates	Fully compliant with the requirements for Android Enterprise Recommended Rugged Devices. Quarterly security updates at least for five years from the launch.
Major upgrade	At least one major upgrade to Android 10 or higher.

Accesorios

Accessories

Included	Smartphone, battery, i.safe PROTECTOR 2.0 USB cable, i.safe PROTECTOR 3.0 USB cable charger, quick start manual and safety instructions

Descargas

Descargar hoja de datos PDF aqui

APPROVALS

• ATEX Zone 2/22
  II 3G Ex ic IIC T4 Gc IP64
  II 3D Ex ic IIIC T135°C Dc IP64

• IECEx Zone 2/22
  Ex ic IIC T4 Gc IP64
  Ex ic IIIC T135°C Dc IP64
• CSA
  (approved for North America)
  Class I Division 2, Groups A, B, C, D, T4
  Class II Division 2, Groups F, G, T135°C
  Class III Division 2
